| FEATURES |
- Non-reversible design for reliable spring action
- Heavy duty spring
- Corrosion resistant alloy
- Wear resistant Delrin Cams, ½" lift
- Tamper-proof spring housing eliminates unqualified field
adjustments
- Light weight saves freight and handling costs
- Durable construction, long life
- Designed especially for foam construction
- Specify Left or Right Hand when Ordering
|
|
|
SPECIFICATIONS
|
| Overall
Length |
- |
5 1/8" |
| Material |
- |
Aluminum or Zinc |
| Finishes |
- |
Polished Aluminum
Brushed Aluminum
Polished Chrome
Brushed Chrome
*Other finishes avail. |
| Offsets |
- |
Flush |
| Screw
Holes |
- |
¼" Hole, 82°
Countersunk |
| Shipping
Weight |
- |
Aluminum 1.8 lbs./pair |
| Hinge
Load Capacity |
- |
150 lbs., 1 pair
aluminum |
|
